REPLIGEN XCell ATF10 User Manual

XCell
TM
ATF System with C410:V4B Controller User Guide
92
Profibus Address
Tagname plc in DB31
PLC Address
Definition
Units
Data type
Byte #
Bit #
Structure
Tagname in structure
0
OutputPageX
ActiveDataPage
%DB31.DBW310
Active Data Page
Int-16
1
2
0
OutputPageX
ATF_HeartBeat
%DB31.DBX312.0
ATF Heartbeat
Byte
1
OutputPageX
Rem_Profibus
%DB31.DBX312.1
ATF Remote Mode (Profibus)
2
OutputPageX
ATF_Trouble
%DB31.DBX312.2
ATF Common Trouble Alarm
3
OutputPageX
ATF_Running
%DB31.DBX312.3
ATF Run Status
4
OutputPageX
Pump_Alarm_0
%DB31.DBX312.4
Pump Alarm
5
OutputPageX
Pump_Alarm_1
%DB31.DBX312.5
Power Loss While Pump Running Alarm
6
OutputPageX
Pump_Alarm_2
%DB31.DBX312.6
P2 High High Pressure Alarm
0
3
OutputPage3
EFLOWMAXSP
%DB31.DBD604
Max Exhaust Flow Setpoint
LPM
Real
4
5
6
7
OutputPage3
EFLOWMINSP
%DB31.DBD608
Min Exhaust Flow Setpoint
LPM
Real
8
9
10
11
OutputPage3
PTIMEMAXSP
%DB31.DBD612
Max Pressure Flow Setpoint
SEC
Real
12
13
14
15
OutputPage3
PTIMEMINSP
%DB31.DBD616
Min Pressure Flow Setpoint
SEC
Real
16
17
18
19
OutputPage3
ETIMEMAXSP
%DB31.DBD620
Max Exhaust Flow Setpoint
SEC
Real
20
21
22
23
OutputPage3
ETIMEMINSP
%DB31.DBD624
Min Exhaust Flow Setpoint
SEC
Real
24
25
26
27
OutputPage3
PV1MAX
%DB31.DBD628
Flow Proportional Valve Max Value
%
Real
28
29
30
31
OutputPage3
PV1MIN
%DB31.DBD632
Flow Proportional Valve Min Value
%
Real
32
33
34
35
OutputPage3
PV2MAX
%DB31.DBD636
Exhaust Proportional Valve Max Value
%
Real
36
37
38
39
OutputPage3
PV2MIN
%DB31.DBD640
Exhaust Proportional Valve Min Value
%
Real
40
41
42
43
OutputPage3
PRV1MAX
%DB31.DBD644
Pressure Regulator Maximum Value
BAR/PSI
Real
44
45
46
47
OutputPage3
PRV1MIN
%DB31.DBD648
Pressure Regulator Minimum Value
BAR/PSI
Real
48
49
50
51
OutputPage3
PRV2MAX
%DB31.DBD652
Exhaust Regulator Maximum Value
BAR/PSI
Real
52
53
54
55
OutputPage3
PRV2MIN
%DB31.DBD656
Exhaust Regulator Minimum Value
BAR/PSI
Real
56
57
58
59
%DB31.DBD660
60
61
62
63
%DB31.DBX664
Output Page 4
