ResMed ApneaLink User Manual

4
Viewing Recordings
The index card box is used for the administration of patient data, recordings,
and reports.
Click this icon to open the report selected in the index card box. The report will
show the recording results, including the risk indicator.
Click this icon to open the recording selected in the index card box. The signal
view is used to display the actual signal curve, together with the detected
events.
Further Information
Refer to the Clinical Guide for further instructions on using ApneaLink and the
associated software correctly and safely. This manual is available for reference
in the “Help” menu. The menu also includes a patient information that can be
printed when required.
System Requirements for Software Operation
Software Minimum Hardware Requirements
• Adobe Acrobat Reader
(min. Version 4)
The ApneaLink software is compatible
with the following operating systems:
• Microsoft Windows 2000 (no Service
Pack required)
• Microsoft Windows XP Home/
Professional (no Service Pack required)
• Microsoft Windows Vista (32 bit and 64
bit versions)
• Microsoft Windows 7 (32 bit and 64 bit
versions)
Note: Local administrator rights are
required for installation under Microsoft
Windows 2000, XP, Vista and 7.
• Pentium II 233 MHz or equivalent
processor
• 1 GHz processor for Windows Vista and
Windows 7
• 128 MB RAM for Windows 2000 and XP
• 1 GB of system memory for Windows
Vista and Windows 7
• 100 MB available hard disk space
(sufficient for 6 recordings)
• Open USB port connection
• CD-ROM drive
• Minimum screen resolution: 800x600
pixel, high color (16 bit)

ResMed ApneaLink Specifications

General

Data Storage	Internal memory
Device Type	Home Sleep Apnea Testing Device
Measurements	Airflow, respiratory effort, pulse rate, oxygen saturation
Software Compatibility	ResMed ApneaLink software
Battery Life	Up to 10 hours
Intended Use	Diagnostic screening for sleep apnea
