ResMed stellar series User Manual

2
Stellar at a glance
The Stellar comprises:
• Stellar device • Hypoallergenic air filter • AC power cord • Carry bag • 2 m air tubing •
ResMed USB stick • Low pressure oxygen connector.
The following optional components are compatible with Stellar:
• 3 m air tubing • SlimLine™ air tubing • Clear air tubing (disposable) • H4i™ heated
humidifier • Antibacterial filter • Heat moisture exchanger filter (HMEF) • ResMed XPOD
oximeter • Nonin™ pulse oximetry sensors • FiO
2
monitoring kit (external cable, T-piece
adapter) • FiO
2
monitoring sensor • Stellar Mobility bag • ResMed Leak Valve • Tubing wrap
• Stellar DC/DC converter.
WARNING
The Stellar should only be used with air tubing and accessories recommended by
ResMed. Connection of other air tubing or accessories could result in injury or
damage to the device.
1 Remote alarm connection is product model dependent.
Handle
Infrared connection
for humidifier
Air outlet
H4i connector
plug and AC
connection
Oxygen inlet
Air filter cover
XPOD pulse oximeter connection
FiO
2
sensor connection
Data port for USB stick
Data port for direct PC connection
DC power socket
AC power socket
Power on/standby switch
Remote alarm connection
1

ResMed stellar series Specifications

General

Data Storage	SD card
Device Type	Ventilator
Modes of Ventilation	CPAP, S, S/T, T
Power Supply	AC 100-240V, 50/60Hz
Operating Temperature	5°C to 40°C
Operating Humidity	10% to 95% (non-condensing)
Operating Altitude	Up to 2500 meters
Sound Level	30 dBA
Humidification	Integrated heated humidifier
Connectivity	Wi-Fi
