Resol DeltaSol BS/3 User Manual

D e lt a S o l
®
BS/3
© RESOL 10082_deltasol_bs/3.monus.indd
13 |
Legend:
Symbol Specification
x Channel is available
x* Channel is available if the corresponding option is activated.
s Channel is specifically available in this system layout
Adjustment Channels
Channel Description Factory setting Page
Arr x System 3 20
DT O x Switch-on temperature difference 12.0 °Ra [6.0 K] 20
DT F x Switch-off temperature difference 8.0 °Ra [4.0 K] 20
S MX x Maximum tank temperature 140 °F [60 °C] 21
EM x Emergency temperature collector 270 °F [130 °C] 21
CMX s Maximum collector temperature
230 °F [110 °C] 22
OCN x Option minimum limitation OFF 23
CMN x* Minimum collector temperature 50 °F [10 °C] 23
OCF x Option antifreeze OFF 23
CFR x* Antifreeze temperature 40.0 °F [4.0 °C] 23
O TC x Option tube collector OFF 24
TCST x* OTC starting time 07:00 24
TCEN x* OTC ending time 19:00 24
TCRU x* OTC runtime 30 s 24
TCIN x* OTC standstill interval 30 min 24
OHQM x Option energy metering OFF 24
FMAX x* Maximum flow 6.0 l 24
MEDT x* Antifreeze type 1 24
MED% x* Antifreeze concentration (only if MEDT = propylene or ethylene) 45 % 24
MAN1 x Manual operation R1 Auto 26
MAN2 x Manual operation R2 Auto 26
LANG x Language En 26
UNIT x Temperature unit °C 26
RESE x Reset - back to factory defaults 26
W0030100 Version number
