DL2 Datalogger
This additional module enables the acquisition and storage of large amounts of data (such
as measuring and balance values of the solar system) over a long period of time. The DL2
can be configured and read-out with a standard internet browser via its integrated web
interface. For transmission of the data stored in the internal memory of the DL2 to a PC,
an SD card can be used.
The DL2 is appropriate for all controllers with RESOL VBus
®
. It can be connected directly
to a PC or router for remote access and thus enables comfortable system monitoring for
yield monitoring or for diagnostics of faults.
RESOL DL2 Article no.: 180 007 10
VBus
®
/ USB interface adapter
The new VBus
®
/ USB interface adapter is the interface between the controller and a
personal computer. With its standard mini-USB port it enables a fast transmission of system
data via the VBus
®
for processing, visualizing and archiving. A full version of the RESOL
ServiceCenter software is included.
RESOL VBus
®
/ USB interface adapter Article no.: 180 008 50
VBus
®
/ PWM interface adapter
The VBus
®
/ PWM interface adapter is used for the speed control of a pump via a PWM or
0-10 V signal. Via the VBus
®
, the adapter receives information from the controller about the
necessary pump speed. The speed is converted into a PWM or direct voltage signal and put
out to the corresponding terminals.
RESOL VBus
®
/ PWM interface adapter Article no.: 180 008 60
AM1 Alarm module
The AM1 alarm module is designed to signal system failures. It is to be connected to the
VBus
®
of the controller and issues an optical signal via a red LED if a failure has occurred.
The AM1 also has a dry contact relay output, which can e. g. be connected to a building
management system (BMS). Thus, a collective error message can be issued in the case of a
system failure.
RESOL AM1 Alarm module Article no.: 180 008 70
VBus
®
/ LAN interface adapter
The VBus
®
/ LAN interface adapter is designed for the direct connection of the controller
to a PC network or router. It enables easy access to the controller via the local network of
the owner. Thus, controller access and data charting can be effected from every workstation
of the network. A full version of the RESOL ServiceCenter software is included.
RESOL VBus
®
/ LAN interface adapter Article no.: 180 008 80
