DeltaSol
®
BS
© RESOL 06177 deltasol_bs1.monen.indd
| 8
3. Controller parameter and indication channels
3.1 Channel-overview
Legend:
x*
Corresponding channel is available if the appropriate option
is activated.
Corresponding channel is only available if the option heat
quantity measurement is activated (OWMZ).
MEDT
The channel antifreeze content (MED%) is only shown if a
medium other than water or Tyfocor LS / G-LS (MEDT
0 or 3) is used. The adjustment is only appropriate when
using other types of antifreeze.
Corresponding channel is only available if the option heat
quantity measurement is deactivated (OWMZ).
Please note:
S3 and S4 are only indicated if sensors are connected.
channel specification page
COL x Temperature collector 1 9
TST x Temperature tank 1 9
S3 x Temperature sensor 3 9
TRF
Temperature return sensor 9
S4
Temperature sensor 4 9
h P x Operating hours relay 1 9
kWh
Heat quantity kWh 10
MWh
Heat quantity MWh 10
DT O x Switch-on temperature difference 10
DT F x Switch-off temperature difference 10
S MX x Maximum temperature tank 1 11
EM x emergency temperature collector 1 11
channel specification page
OCN x Option minimum limitation
collector 1
11
CMN x* Minimun temperature collector 1 11
OCF x Option antifreeze collector 1 11
CFR x* Antifreeze temperature collector 1 11
OREC x Option reccoling 12
O TC x Option tube collector 12
OHQM x Option WMZ 12
FMAX
Maximum flow 10
MEDT
Antifreeze type 10
MED% MEDT Antifreeze content 10
HND x Manual operation relay 1 12
LANG x Language 12
UNIT x Change over °FAH / °CEL 12
PROG XX.XX Program number
VERS X.XX Version number
