en
39
InstallationIndications, functions and optionsMessages Commissioning Operation and function
6 Commissioning
When the hydraulic system is lled and ready for operation, connect the controller
to the mains.
The controller runs an initialisation phase in which all symbols are indicated in the
display. The directional pad ashes red.
When the controller is commissioned or when it is reset, it will run a commis-
sioning menu after the initialisation phase. The commissioning menu leads the user
through the most important adjustment channels needed for operating the system
and starts with the indication of the BX version number.
Commissioning menu
The commissioning menu consists of the channels described in the following. In
order to make an adjustment, push button ➄. Ⓢ starts ashing and the adjust-
ment can be made. Acknowledge the message by pressing button ➄. Press button
❸, the next channel will appear on the screen.
Button navigation
Adjustment mode
➄
➄
❹ ❷
❸
Changing a value
Con rming a value
to the next
parameter
1. Language:
Î Adjust the desired menu language.
2. Temperature unit:
Î Adjust the desired temperature unit.
3. Time:
Î Adjust the clock time. First of all adjust the hours,
then the minutes.
4. Date:
Î Adjust the date. First of all adjust the year, then the
month and then the day.
Commissioning
