Code
The access to some adjustment values can be restricted via a user code (custom-
er).
1. Installer 0262 (Factory setting)
All menus and adjustment values are shown and all values can be altered.
2. Customer 0000
The installer level is not shown, adjustment values can be changed partly.
For safety reasons, the user code should generally be set to the customer code
before the controller is handed to the customer!
Î In order to restrict the access, enter 0000 in the menu item CODE.
The display changes to the status level. The short menu shown will then be available
in the adjustment level. The short menu suits the selected system.
Î In order to authorise access to the installer level, enter 0262 in the menu
item CODE.
Short menu
Channel
Factory
setting
Adjustment range Designation
TIME 12:00 00:00 … 23:59 Time
DT O 6 1.0 … 50.0 Switch-on temperature difference store
DT F 4 0.5 … 49.5 Switch-off temperature difference store
DT S 10 1.0 … 50.0 Set temperature difference store
S MAX 60 4 … 95 Store maximum limitation
DT1O 6 1.0 … 50.0 Switch-on temperature difference store 1
DT1F 4 0.5 … 49.5 Switch-off temperature difference store 1
DT1S 10 1.0 … 50.0 Set temperature difference store 1
S1MAX 60 4 … 95 Store maximum limitation store 1
DT2O 6 1.0 … 50 Switch-on temperature difference store 2
DT2F 4 0.5 … 49.5 Switch-off temperature difference store 2
DT2S 10 1.5 … 50.0 Set temperature difference store 2
S2MAX 60 4 … 95 Store maximum limitation store 2
LST2 On On / OFF Loading store 2 on
MAN1 Auto Auto / On / OFF / n LO / n HI Manual mode pump 1
MAN2 Auto Auto / On / OFF / n LO / n HI Manual mode pump 2
MAN3 Auto Auto / On / OFF / n LO / n HI Manual mode pump 3
MAN4 Auto Auto / On / OFF Manual mode pump 4
CODE 0000 0000 / 0262 User code
8 User code and short menu – Adjustment values
In the case of an error, the directional pad starts ashing red and a message is indi-
cated in the status display. A warning triangle is additionally indicated. If more than
one error or fault condition has occurred, only the one with the highest priority will
be displayed as a message in the status display.
Error message Value Cause Solution
FS1 … 7; FS6, 8
-88.8 Short circuit at sensor 1 … 7
Check the cable.
888.8 Broken cable at sensor 1 … 7
EVFS 9999 Error at Grundfos Direct Sensor
TM
VFS
Sensor fault. Check and, if necessary, correct the connection of the sensor plugs. If a sensor
signal does not appear, the sensor has to be replaced.
ERPS 9999 Error at Grundfos Direct Sensor
TM
RPS
ELEAK Measured minimum pressure Leakage error Check the system for a leakage.
EPRES Measured maximum pressure Pressure error Check the functioning of the valves and pumps.
EFLOW
Flow rate error
Threshold values for VFS 1 - 10: 1.0 - 1.1 l/min
Threshold values for VFS 2 - 40: 2.0 - 2.1 l/min
Check the pump.
Check whether a ow rate exists.
PARAM Remote parameterisation Do not parameterise the controller via the push buttons during remote parameterisation.
After the error has been removed, the error message disappears.
In the case of a sensor error, the system is switched off, and a message appears on
the display marked by an “E”. Additionally, a corresponding value for the error type
assumed is indicated.
9 Messages
