Part List - SureFit (SFDomes
SUREFIT (SF) - STD, OPEN & CLOSED DOMES
Description Bag (10 pcs)
DOME,REC,STD,BAG,10PC 21432300
DOME,OPEN,REC,SM,BAG,10PC 21432400
DOME,OPEN, REC,MDM,BAG,10PC 21432500
DOME,OPEN, REC,LGE,BAG,10PC 21432600
DOME,CLOSED,REC,SM,BAG,10PC 21432000
DOME,CLOSED,REC,MDM,BAG,10PC 21432100
DOME,CLOSED,REC,LGE,BAG,10PC 21432200
SUREFIT (SF) - POWER DOMES
DOME,PWR REC,SM,BAG,10PC 21432700
DOME,PWR REC,MDM,BAG,10PC 21432800
DOME,PWR REC,LGE,BAG,10PC 21432900
Large petal
The dome must be correct mounted. Check
that the collar completely covers the ribbed
end rec tube. Push the large petal forward
Push the largest petal back, then
press the STD/tulip dome over
the ribbed end of the rec tube
Ensure that the large petal on the STD
(tulip) dome is outside the small petal
