Part List - HSG Parts 61-DRWC (RHI)
All HSG parts are nano coated
TOP HSG, mic lters & PB
If the mic lters are damaged (they are mounted inside the TOP
HSG) or the TOP HSG is damaged, the TOP HSG ASM can be
replaced. Choose either the TOP HSG ASM or a FILTER REPL
KIT.
Due to the mechanical construction of the HI and a sealing inside
the HI, the BOT HSG must not be replaced. If it is damaged and
needs to be replaced, the complete HI should be returned for
repair/replacement.
COLOUR TOP HSG ASM FILTER REPL KIT
GOLD 21513270 21618870
WARM GREY 21513271 21618871
ESPRESSO 21513272 21618872
DEEP BLACK 21513273 21618873
BRONZE 21513274 21618874
CHAMPAGNE 21513275 21618875
SPARKLING SILVER 21513276 21618876
GRAPHITE 21513277 21618877
FILTER REPL KIT:
Pin tool with pin,
TOP HSG ASM
Filter repl guide
