Appendix B. - Technical Specifications
General
Frequency Range GMRS (RX & TX)
Memory Channel 30 GMRS Channels + 11 NOAA Weather
Operation Voltage DC7.4V ±10%
Battery Capacity 1500mAH (Li-Ion)
Frequency Stability ±2.5ppm
Operating Temperature -20℃ to +60℃
Mode of Operation Simplex
Antenna Impedance 50ohm
Transmitter Part
FM Modulation 11K0F3E@12.5KHz
Spurious Emission 13dBm＜1GHz， -13dBm＞1GHz
Adjacent Channel Power 60dB @ 12.5 KHz
Transmission current ≤600mA
Receiver Part
Receive Sensitivity 0.25μV (12dB SINAD)
Adjacent Channel Selectivity ≥55dB@12.5KHz
Inter Modulation and Rejection ≥55dB@12.5KHz
Conducted Spurious Emission ≤-57dB@12.5KHz
Rated Audio Power Output 1W @16ohms
Receive current ≤350mA
Rated Audio Distortion ≤5%
NOTE: All specifications may be modified without prior notice or liability. Thank you.
13
