Retsch SM300 - Overview Table of the Parts of the Device

Operating the machine
22
5.3 Overview table of the parts of the device
Element
Description
Function
A
Safety guard for the feed hopper
Prevents contact with the feed hopper
B
Plunger
Releases the material feed chute in pulled state.
Pushes grinding material onto the rotor.
C
Metering plunger
Pushes the grinding material into the feed chute area of
the fill plunger
– Extended: grinding material can be loaded.
– Inserted: grinding material remains in the area
of the fill plunger.
D
Locking pin
Prevents, blocks or releases the fill plunger.
– Extended: free movement of the
fill plunger is possible
– Released: fill plunger engages in the uppermost
position
E
Mini locking pin
Engages the door lock
F
Door lock grip
Enables the door to be opened
G
Control panel
Starts and stops the device, adjusts the speed
H
Parallel section rotor
Grinding tool
I
Bottom sieve
Influences the ultimate fineness of the grinding material
through the size and type of perforation
J
Ring filter
Air outlet and filter for material to be ground
K
Collecting receiver
Collects ground material
L
On/off switch (main switch)
Disconnects and connects the device to the mains.
– ON = LED (red) STOP lights up
– OFF = all LEDs are extinguished
M
16A socket
Power supply
N
Housing fan
Cools the housing area
O
Rotor shaft
Accommodates the grinding tool
P
Cutting bars
Counterpart to grinding tool
R
Feed hopper
Feeding the grinding material
S
Feed hopper fixing screws
Safety bolts for the feed hopper
T
Grinding area door
Closes the grinding area
