Assembling and using the cyclone
30
Fig. 17: Fastening the discharge flange
• Insert the retrofit dust removal (U).
• Tighten the screw (U1).
Fig. 18: Inserting the plug for the sliding block
• Insert the plug (HS) into the back (flat surface) of the sliding block (NS).
Fig. 19: Inserting the sliding block
• Guide the sliding block with plug into the aluminium profile.
