6) Use the (4) ¾” wood screws to attach U-shaped supports into
oor of the cabinet.
7) Push the (2) rear metal sockets to the rear of the cabinet and attach both
sides using the (2) ½” wood screws.
This will ensure complete stability of your baskets.
5) Using the provided ½” wood screw, attach slide to face frame of cabinet while making sure that the front of the slide is ¼” back
from the opening.
1/4”
8) Carefully re-engage the baskets into the slides. Be careful not to force the baskets into the slides as this could cause damage.
(Note: if installing into a frameless application you can simply use the same ½” screw and install into the side wall of the cabinet.)
Note: To ensure optimal
performance it is
recommended that the rear
sockets are perfectly aligned.
