BATTERY STATUS:
•Thebatteryisemptyifthemodelbeginstolosethrust.Landinordertoavoidcrashing.
9 CHANGING THE PROPELLERS
If the rotor blades on the model are damaged, they must be replaced.
To do so, proceed as follows:
9A Screw out the screw in the center of the rotor blade in counter-clockwise direction.
9B Hold the faulty rotor blade with two fingers and pull it off carefully to the top.
9C Place the new rotor blade on the shaft and screw in the fixing screw carefully in
clockwise direction. Caution: Do not tighten the screw too tightly, as this could
damage the thread.
9DWhenmountingtherotorblade,pleasenotethatthereareright-turning(A)and
left-turning (B) rotor blades.
TROUBLESHOOTING
Problem: The propellers do not move.
Cause: •Noconnectionhasbeenestablished.
•Thebatteryistooweakordepleted.
Remedy: •Switcheverythingoffandswitchonagaininthecorrectsequence.
•Chargethebattery.
Problem: The model stops and descends during flight for no apparent reason.
Cause: •Thebatteryistooweak.
Remedy: •Chargethebattery.
Problem: The model cannot be controlled with the remote control.
Cause: •TheON/OFFswitchisinthe„OFF“position.
•Thebatterieswerenotinsertedcorrectly.
•Thebatteriesdonothaveenoughpower.
Remedy: •SettheON/OFFswitchtothe„ON“position.
•Checkwhetherthebatteriesareinsertedcorrectly.
•Insertnewbatteries
Problem: The model only turns on its vertical axis or rolls over when started.
Cause: •Incorrectarrangementofthepropellers.
Remedy: •Installthepropellersandarmsasoutlinedinthemanual.
Problem: The model will no longer fly loops.
Cause: •Batterytooweak.
Remedy: •Chargethebattery.
20 21
Additional tips and tricks can be found online at www.revell-control.de.
www.revell-control.de
SERVICE NOTES
Go to www.revell-control.de for ordering information
and tips on replacing spare parts, plus other useful
information on all Revell Control models.
