Reverso FPS-80 - FPS-150 Technical Specifications

16
Reverso Pumps, Inc.
FPS-150 Technical Specications
Nominal Flow Rate System rated at 150 GPH (568 LPH). Actual ow rate may vary due to conditions of installation.
Voltage 12V or 24V DC
Circuit Breaker
10A / 12V DC
5A / 24V DC
Pump Type Gear
Pump Body Nickel-plated brass
Pump Shaft Stainless steel
Pump Rating IP67
Self-priming 4.9 ft
(1.5m) with foot valve above liquid level
Control Digital, Touchscreen, or Mechanical
Inlet / Outlet 1/2” Male JIC
Recommended
Hose
Minimum 1/2” inner diamter (ID) using quality approved fuel line materials
Filter Torque Values
Bowl Screws 8 Nm (70.8 in-lbs)
Lid 8 Nm (70.8 in-lbs)
Bleed Screw 4 Nm (35.4 in-lbs)
Spare Parts
Part # Description
58-01010 Separ 01010, 10 micron element
58-01030 Separ 01030, 30 micron element
58-01060 Separ 01060S, 60 micron element, stainless
64-10362 Separ lid gasket
64-10361 Separ bowl gasket
05-0839 Vacuum gauge
