Reverso FPS-80 - FPS-150 Dimensions

17
Reverso Pumps, Inc.
FPS-150 Dimensions
44.98 17.71
0.69 0.27
51.00 20.08
2.44 0.96
0.79
R0.31
INLET
11.26
4.44
5.98 2.35
46.36 18.25
21.42
8.44
17.59
6.93
54.24 21.35
Power In
Ethernet Port
27.62 10.87
8.21 3.23
12.92
5.09
8.21 3.23
OUTLET
Fuel Polishing System - 150GPH
Marine Model - 12vDC - Basic
Digital Controller
DO NOT SCALE DRAWING
FPS-150-ER-R_A
SHEET 1 OF 4
2/2/2021
JC
UNLESS OTHERWISE SPECIFIED:
SCALE: 1:10
WEIGHT:
REV
DWG. NO.
A
SIZE
TITLE:
REVERSO PUMPS
NAME
DATE
COMMENTS:
Q.A.
MFG APPR.
ENG APPR.
CHECKED
DRAWN
DIMENSIONS ARE IN INCHES TOLERANCES: FRACTIONAL
1/64
ANGULAR: MACH
BEND
0.2
TWO PLACE DECIMAL
.01
THREE PLACE DECIMAL
.005
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS
DRAWING IS THE SOLE PROPERTY OF
REVERSO PUMPS
ANY REPRODUCTION IN PART OR
AS A WHOLE WITHOUT THE WRITTEN
PERMISSION OF
REVERSO PUMPS
IS PROHIBITED.
Part #: 19-2001-02
All Dimensions for Reference Only
Secondary Dimensions in Centimeters
TECHNICAL SPECIFICATIONS Port Size - 1/2" MJIC
Weight - 25lbs. / 11.34 kg (estimated)
Power - 10A @ 12vDC
Flow Rate - 150 gph/ 567.8 Lph
JC
6/11/2020
Dimensions are the same for 24V DC, and versions with touchscreen or mechanical control panels.
