3
Reverso Pumps, Inc.
System Overview
Serial number plate
V
acuum gauge
Filtration : Separ Filter
Inlet
Base
Drain valve -
Push in and turn counter-
clockwise to open
Control panel with digital, touchscreen,
or mechanical control
Power in
Hinged cover -
covers pump
Outlet
8
10
9
7
3
6
5
4
1
2
1
5
3
7
8
9
10
2
6
4
2
4
