Reversomatic RERV-S200 - Page 6

*
22
*
Parts List
4
*
*
*Optional Parts:
*
5
1
2
2
9
3
10
11
6
12
6
19
*
Maxum Series
model:
RHRV-S200A
Aluminum Core
RHRV-S200P
Polypropylene Core
RERV-S200ES
Enthalpy Core
20*
Motorized damper spring return built-in
120V Motorized spring return damper
9397
9398
1
1
1
1
1
1
Reference Description
Part no.
RHRV-S200A RHRV-S200P
RERV-S200ES
QTY. QTY. QTY.
1 HRV / ERV - Lid, Pan Assembly
9391
1 1 1
2 Polypropylene Collar 6” Dia.
PBD6C
2
2 2
3
Aluminum Core
9392
1 n/a n/a
Polypropylene Core
9393
n/a 1 n/a
Enthalpy Core
9394
n/a n/a 1
Filter 10 1/2" x 12" (MERV - 4)
9395
2 2 2
4
Temperature Sensor
9326
1
1 1
5
6”ø Polypropylene Backdraft Damper
PBD6
2 2 2
6
Blower - Supply / Exhaust
013070
2 2 2
7
Adjustable Door Latch
9319
1 1 1
8
Drain Spout Assembly
9320
2 2 2
9
Core Locking Bracket
9321
1 1 1
10
Nut
014016
1 1 1
11
Safety Switch
9322
1 1 1
12
Main Control Board - Superior & Project
9356
1 1 1
Main Control Board Bracket
9355
2 2 2
13
Door Hinges
9328
1 Set 1 Set 1 Set
14
Mounting Brackets
011136
4 4 4
15
“ T ” Connector
9330
1
1 1
16
Webbing/Brackets/Ladder Locks
9332
2 Sets 2 Sets 2 Sets
17*
Chains/Springs/Brackets
9354
1 Set 1 Set 1 Set
18*
Drain Pipe
9331
1 1 1
19*
6”ø
6”ø
21*
22*
4
6
7
8
13
14
15
16
17
18
