HARDWARE CAPABILITIES:
CONTROLLER INTERFACE
• High-brightness, 2.8" QVGA TFT LCD with resistive touchscreen
• Integrated BUMP wireless interface for configuring and reading BumpTags on batteries
• Integrated Bluetooth 4.0/LE support for wireless real-time monitoring, control, and firmware
upgrades (Android, Apple iOS, and Windows (future) mobile devices)
• Integrated USB On-The-Go (OTG) port for direct connection to Windows PC for firmware
updates, as well as powering/charging mobile devices
• Powerful 32-bit ARM Cortex-M3 main processor, plus co-processors for Bluetooth and NFC
• Two (2) external data ports for controlling legacy CellPro PowerLab Battery Workstations
CHARGER ENGINES
• Dedicated main and safety supervisor processors for each unit/channel
• Standard JST-XH balance connectors capable of direct connect of any cell count
(8S 9-pin connector on PowerLab 8 Touch, 6S 7-pin connector on PowerLab 6 Touch)
• Independent, variable per-cell balancing of up to 1000 mA per cell
• Reverse polarity protection on all inputs and outputs (when using properly fused main
charge leads)
• Regenerative Discharge allows full power “green” discharge back into Pb battery power
source
MODEL COMPARISONS:
Model
Charger
Channels
Max Cells
Supported
Input
Voltage
Range
Input
Amps
Max
Output
Amps/Watts
Per
Channel
Internal
Discharge
Amps/Watts
Per
Channel
Regen
Discharge
Amps/Watts
Per
Channel
PowerLab 6
Touch
1
LiXX - 6s
NiXX- 19s
Pb 12V
10-32V
40A
40A
1000W
8A
50W
40A
1000W
Dual
PowerLab 6
Touch
2
80A
PowerLab 8
Touch
1
LiXX - 8s
NiXX- 21s
Pb 12V
10-48V
40A
40A
1350 W
10A
95W
40A
1350W
Dual
PowerLab 8
Touch
2 80A

Revolectrix PowerLab 8 Touch Specifications

General

Brand	Revolectrix
Model	PowerLab 8 Touch
Category	Battery Charger
Language	English
