Revv Owner’s Manual - 22
Foot Switch Connection
This connection both powers your footswitch & allows it to control your
Revv.
Should the provided footswitch cable fail, any Ethernet cable can be
used. However, this cable sends data between the amplifier & footswitch
& if a lower quality cable is used incorrect switching or erratic behavior
may occur. A high quality cable is recommended, which can be provided
by Revv should you need a replacement.
Speaker Cab Lighting
Revv speaker cabinets each have an illuminated up logo which is pow-
ered from the cab lighting jack on Revv amplifiers. This is a 4 pin DIN jack
that should be connected to the 4 pin DIN jack of a Revv speaker cabinet
only. The logo will change colors in conjunction with the channel switch-
ing of your head.
Note: This jack can only be used with Revv speaker cabinets.
