Rexel 1150 S2 - Model 250 S5 Cutting Head

Deskside and Office 230vissue7 9 01/02/02
ILLUSTRATED PARTS MANUALS
SERIES 7 SHREDDERS – 230v
DESKSIDE AND OFFICE MODELS
MODEL 250 S5 CUTTING HEAD
No Description Part Qty Comments
1 Side Frame (Motor) D53141 1
2 1:1 Gear D53530 2
3 Circlip, 17mm TRU88 1
4 Lost Motion Collar D53790 1
5 Spur Gear Assembly A53650 1
6 Gearbox Spacer D53520 1
7Pin, dowel PEG91 6
8 End Closing Plate D53831 1
9 Bolt, M5 x 70MM, Plated SCM151 5
10 Ball Bearing BR23 5
11 Ball Bearing BR28 2
12 Compound gear assembly A53547 1
13 Screw, M5 x 12 CSK Nyloc SCM152 2
14 Screw M5 x 10 SCM9 2
15 Washer, M5 Shakeproof SHK10 2
16 Key, Woodruff KEY33 1
17 Deflector Tab D53067 2
18 Motor, 300W SL20-303 1
19 Screw, M6 x 12 SCM15 6
20 Washer, ¼” Shakeproof SHK4 12
21 Tie bar, top motor D53032 1
23 Motor fan Supplied with motor
24 Tie bar D53012 1
25 Infeed Chute (rear) D53036 1
26 Bin Full Flap D53033 1
27 Grommet SL18-333 2
28 Not used
29 Cutter Shaft – Drive D53005 1
30 Grommet GRM22 1
31 Pop Rivet RTS68 4
32 Snap Bush SL18-369 1
33 Side Frame (bearing) D53040 1
34 Location plate D53037 2
35 Vibration Isolator SL18-305 4
36 Washer, plain PLN4L 12
37 Nut, M6 NM5 8
38 Nut Protection Cap SL18-325 2
39 Infeed Chute (front) D53035 1
40 Lock-nut 9076BI 4
41 Collar, Cutter Shafts 44808 2
42 Stripper Bar (security) D53011 2
43 Screw, M6 x 16 CSK, Skt Hd SCM104 2
44 Cutter Shaft – Driven D53004 1
45 Stripper 44815 324
46 Spacer 9115B 324
47a Cutter 14737 162
47b Cutter, knurled 14738 162
48 Key 5x5x16 KEY32 2
SIDE FRAME ASS. (BEARING) A53043SP 1 Comprises 10, 33, 34
SIDE FRAME ASS. (MOTOR) A53147SP 1 Comprises 1, 10, 34
CUTTING HEAD ASS. A53062SP 1 Comprises All except 18, 23, 30, 22, 32, 13
END PLATE ASS. A53153 1 Comprises 8, 10, 11
GEARBOX SPACER ASS. A53531SP 1 Comprise 6, 7
SHREDDER OIL, 500ML 40100 1
