Deskside and Office 230vissue7 4 01/02/02
ILLUSTRATED PARTS MANUALS
SERIES 7 SHREDDERS – 230v
DESKSIDE AND OFFICE MODELS
MODEL 250 S2 CUTTING HEAD
No Description Part Qty COMMENTS
1 1:1 Gear 9709 2
2 ½” Circlip TRU95 2
3 Gear 56 Tooth A44259 1
4 Circlip, 10MM TRU66 1
5 Washer, M10 Flat PLN33 1
6 Compound Gear D44261M7 1
7 Screw, M5 x 16 SCM20 4
8 Washer, M5 Shakeproof SHK10 4
9 Screw, M6 x 12 SCM15 4
10 Washer, ¼” Shakeproof SHK4 12
11 Motor, 75W SL20-284 1
12 Cutter Shaft – Drive D53017 1
13 Pin, Gear Locating PM1 3
14 Tie Bar D53012 2
15 Stripper Plate (rear) D53008 1
16 Stripper Plate (front) D53009 1
17 Side Frame (Bearing) D53031 1
18 Grommet GRM20 1
19 Location Plate D53077 2
20 Grommet GRM22 1
21 Nut, M6 NM5 8
22 Vibration Isolator SL18-305 4
23 Nut Protection Cap SL18-325 2
24 Cutter Shaft – Driven D53016 1
25 Deflector Tab D53068 2
26 Bush D53511 4
27 Side Frame (Motor) D53015+ D53094 1 Includes gear shaft
Gear shaft D50083
28 Pop Rivet RTS68 4
CUTTING HEAD ASSEMBLY A53055SP 1 All except 1,3,6,11,12,19,21
SIDE FRAME ASSEMBLY (mtr) A53039SP 1 Comprises 20,27,28
SIDE FRAME ASSEMBLY (brg) A53038SP 1 Comprises 18,20,27
SHREDDER OIL, 500ML 40100 1
29 Motor Earth Wire D50105 1
