ILLUSTRATED PARTS MANUALS
SERIES 7 SHREDDERS – 230v
DESKSIDE AND OFFICE MODELS
SECTION 2 – CUTTING HEAD (ALL MODELS)
Removal
1. Remove top cover away from machine, as described in Section 1.
2. Disconnect two wires from the capacitor (these serve the motor).
3. Disconnect earth lead from the earthings stud.
4. Mark wires to prove their locations, then remove push fit connectors from bin full switch (all models
except 250 S2) and safety switch (MODELS 1150 and 1250). Separate wires from the head
assembly. Leave wires at door switch connected and in place. (Not applicable 250 S2).
5. Open the cabinet door to access four nuts , two forward ones with nuts covers, on screws under the
vibration pads. Remove the covers and four nuts.
6. Lift out the cutting head and place it on the workbench, supported so as not to place load on the bin
full flap (not MODELS 250-S2).
Replacement
1. Refit cutting head on its four fixings, replace lock washers, tighten nuts, and replace nut covers.
2. Re-attach all wires securely (referring to wiring diagram - capacitor (two wires) green/yellow to
earth stud, re-fit microswitch push fit connectors (Not model 250-S2).
3. Replace cover as described in section 1
4. Test operation
