Rexel 1150 S2 - Models 1250 Cabinet

Deskside and Office 230v
24
26/05/99
ILLUSTRATED PARTS MANUALS
SERIES 7 SHREDDERS – 230v
DESKSIDE AND OFFICE MODELS
MODELS 1250 CABINET
NoDescription Part S2S3S4S5Comments
1 Door Assembly A53793 1 1 1
1 Door Assembly A53792 1
2 Door Handle D54140 1 1 1 1
5 Cabinet Assembly A53798 1 1 1
5 Cabinet Assembly A53796 1
6 Screw M4 x 12 Csk SCM81 3 3 3 3
7 Top cover assembly A53637SP 1 1 1 1 Inc LCD Lens & Foam
8 Fused inlet socket
See Electrical
9 Forward Button D53506 1 1 1 1
10 Reverse Button D53504 1 1 1 1
11 Stop button D53503 1 1 1 1
12 Screw No 8 Pozi Pan Plas No 8 SCR707 2 2 2 2
13 Plastic Bin Panel D53830 1 1 1 1
13a Plastic Bin Handle D53820B 2 2 2 2
14 Door Catch, Magnetic SL23-12 1 1 1 1
15 Washer, M8 Flat PLN5/L 4 4 4 4
16 Washer M8 Shakeproof SHK11 4 4 4 4
17 Castor Insert SL18-345 2 2 2 2 Not shown
18 Castor SL18-344 4 4 4 4
19 Door spacer SL18-245 1 1 1 1
20 Door Hinge (Bottom) Bracket D53540 1 1 1 1
21 Screw, M4 x 25 SCM25 2 2 2 2
22 Washer M4 Shakeproof SHK2 2 2 2 2
23 Hinge support plate 45610BI 1 1 1 1
24 Handle Assembly A53625 1
30 Switch cam plate assembly A53622 1
31 Washer, Plain M4 PLN3/L 2
32 Screw, M4 x 10 Pozi Pan SCM45 4
33 Cam Spindle D53626 1
34 Screw SCM25 1
35 Peg D53638 1
36 Switch cam plate D53623 1
37 Cam 14267 1
38 Limit Switch See Electrical
39 Switch cam support bracket D53621 1
Rivet RTS68 1111Not Shown
Spring D53639 1 Not Shown
Gasket (LCD Lens) D53640 1 1 1 1 Not shown
Cabinet Assy (spares) A53798SP 1 1 1
Cabinet Assy (spares) A53796SP 1
Door Assy (spares) A53793SP 1 1 1
Door Assy (spares) A53792SP 1
Door Switch Housing Assy A53548SP 1 1 1 1
Rivet RTS72 4444
40 Door Switch See Electrical
41 Cable Entry Plate D54176 1 1 1 1
