ILLUSTRATED PARTS MANUALS
T300 THERMAL BINDER
220-240V
T300.doc 10
SECTION 2.0 (To serial no A545817)
Replace Lid Moulding
1. Remove lid from top cover, by bowing inwards to release hinge pins.
2. Replace lid.
3. Check that pivot pins are correctly aligned in top cover.
4. Check lid opens and closes correctly.
SECTION 2.1
a. Replacement of Heater Assembly
1. Carry out procedures 1 to 4 in section 1.0.
2. The heater assembly is secured to 2 off heater fixing blocks by four fixing screws.
3. Remove the four fixing screws.
4. Unclip heater wire and thermistor connectors from PCB assembly.
5. Lift and remove heater assembly complete.
6. To reassemble machine, reverse sequence of operation 1 to 5.
b. Replacement of Heater Assembly (Including Thermistor)
1. Carry out procedures 1 to 4 in section 1.0.
2. The heater assembly is secured to 2 off heater fixing blocks by four fixing screws.
3. Remove the four fixing screws.
4. Unclip heater wire thermistor and mains connector from PCB assembly.
5. Lift and remove heater assembly complete.
6. To reassemble machine, reverse sequence of operation 1 to 5.
Issue No 1
