Rexel T300 - Mechanism and Electrics

ILLUSTRATED PARTS MANUALS
T300 THERMAL BINDER
220-240V
T300.doc 6
MECHANISM & ELECTRICS
N
o
Description Part Qty Comments
1 Heater Assembly 230V 600W A52505 1 To Serial No A545817
Heater Assembly 230V 600W A52527 1 From Serial No A545818
2 Heater Extrusion D52503 1 To Serial No A545817
Heater Extrusion From Serial No A545818 Inc in
A52527
3 Heater Fixing Block D52504 2
4
5
6 Compression Spring (clip) D52511 3 To Serial No A545817
7 Thermal Fuse Holder (Clip) D52513
Thermal Fuse Holder (Clip) 4 From Serial No A545818 Inc in
A52527
8 Base Insulation D52514 1
9 Nut Brass M3 Full NM32 2 To Serial No A545817
10 M3 Plain Brass Washer PLN34 1 To Serial No A545817
11 M3 x 12mm C’sunk slot head
brass
SCM145 1 To Serial No A545817
12 M3 x 8 Pozi Pan Rec’d
Plasform
SCR713 12
13 M3 Plain Brass Washer SHK12 1 To Serial No A545817
14 T300 Thermal Binder PCB
230V
SL17-262 To Serial No A545817
T300 Thermal Binder PCB
230V
SL17-299 1 From Serial No A545818
15 Laminator Cordset UK SL4-102 1 To Serial No A545817
Laminator Cordset (Euro) SL4-103 1 To Serial No A545817
Laminator Cordset (Aust) SL4-104 1 To Serial No A545817
Laminator Cordset (Export) SL4-106 1 To Serial No A545817
Laminator Cordset (UK) SL4-199 1 From Serial No A545818
Laminator Cordset (Euro) SL4-120 1 From Serial No A545818
Laminator Cordset (SA) SL4-120 1 From Serial No A545818 fitted
with SL12-43 plug
16 Thermistor Assembly SL17-268 1 To Serial No A545817
Thermistor Assembly 1 From Serial No A545818 inc in
A52527
17 Crimp Terminal Housings SL13-66 2
18 No 4 x ¼” Self Tapper SCR541 1 To serial No A545817
19 M3 Fibre Washer FIB 1 4
Issue No 1
