ILLUSTRATED PARTS MANUALS
T300 THERMAL BINDER
220-240V
T300.doc 13
Replacement of Thermistor
1. Carry out procedures 1 to 4 section 2.1
2. Remove thermistor for connection on PCB.
3. The PCB may be removed to ease replacement. If required refer to section 1 produce 6.
4. Replace thermistor
5. Reverse assembly of operations 3 to 1 if PCB was removed, otherwise 2 to 1.
Issue No 1
