ILLUSTRATED PARTS MANUALS
T300 THERMAL BINDER
220-240V
T300.doc 17
SECTION 7.3
Replacement of insulation
6. Carry out procedures 1 to 4 section 7.1
7. Insulation is secured using double sided sticky tape.
8. Ease free sticky tape from insulation.
9. Remove and replace insulation.
10. Reassemble machine in reverse sequence of operations 1 to 3.
SECTION 7.4
Replacement of Base Moulding
7. Carry out procedures 1 to 5 section 7.1
8. The extrusion/heater assembly will now become free.
9. Place on one side.
10. Remove insulation as procedures 2 to 4 section 7.3
11. Replace base moulding.
12. Reassemble machine in reverse sequence of operations 1 to 4.
SECTION 8.0
Replacement of PCB
4. Carry out procedures 1 to 7 section 6.
5. Replace the PCB
6. Reassemble machine In reverse sequence.
Issue No 1
