ILLUSTRATED PARTS MANUALS
T300 THERMAL BINDER
220-240V
T300.doc 18
SECTION 9.0
Replacement of document support bar/spring/lever arm
8. Carry out procedures 1 to 4 section 6.
9. To remove extension spring unhook from rear screw boss and lever arm.
10. Replace spring.
11. To remove lever arm carry out procedures 1 to 4 section 6, and then 9 to 11 section 6.
12. To remove document support bar, carry out procedures 1 to 5 section 6.0 and procedures 9 to 14 in
section 6.0.
13. Replace document support bar.
14. Reassemble machine by reversing above operations.
SECTION 9.1
Replacement of Buttons
4. Carry out procedures 1 to 8 section 6.0.
5. Replace the buttons, making sure that the grey button is in the aperture marked 1, the red button is In
the aperture marked 0, the yellow button is in the aperture marked ? and the green button in the
aperture marked
