ILLUSTRATED PARTS MANUALS
T300 THERMAL BINDER
220-240V
T300.doc 4
MOULDINGS
No Description Part Qty Comment
1 Service Call Decal D000185 1 Not shown
2 Bottom Moulding D52501 1
3 On Button – Grey D52507 1
4 Off Button – Red D52508 1
5 Programme Select Button – Yellow D52509 1
6 Bind Button – Green D52510 1
7 Lid Pad Print D52516 1
8 Top Cover Pad Print D52517 1
9 No 4 x ½” Pan Plasfast Screw SCR716 6
10 Self Adhesive Rubber Feet SL18-294 4
11 Document Feet D52519 1
12 Spring Arm D52512 1 Not shown
13 Coil Spring D52518 1 Not shown
Issue No 1
