Rexroth Indramat CZM 01.3-02-07 User Manual

610-3.**CKD 30EVIRDOCEsrellortnoC evirD 30EVIRDOCE 5-43
XS1, XS2, XS3 Shield Connections
XS1
Connection for shield:
• Total motor cable shield
• Holding brake
• Motor temperature monitoring
XS2
Connection for shields of cables at X1 and those for the command
communication interfaces.
XS3
Connection for shields of cables at X3 and X10.
6 - 15 mm (for all shield connections)
Note: Always connect the shield connections of the cables
(especially of the motor cables) with a large contact surface.
Allowed outside diameter:
