Rexroth IndraDrive C Mechanical Data 5-1
DOK-INDRV*-HCS02.1****-PR02-EN-P
5 Mechanical Data
5.1 Dimensions
HCS02.1E-W0012
A: minimum mounting clearance (when using accessories HAS02.1);
plus space for cables
B: minimum mounting clearance; plus space for cables
Fig. 5-1: Dimensional drawing HCS02.1E-W0012
