REXROTH HCS02.1 Series User Manual

Rexroth IndraDrive C Electrical Data 6-13
DOK-INDRV*-HCS02.1****-PR02-EN-P
6.7 Power Section – Cooling, Power Dissipation, Insulation
Resistance, Sound Pressure
Designation Symbol Unit HCS02.1E-
W0012
HCS02.1E-
W0028
HCS02.1E-
W0054
HCS02.1E-
W0070
cooling power section forced forced forced forced
volumetric capacity of the
forced cooling
m³/h approx. 24 approx. 24 approx. 40 approx. 40
cooling air flow together for braking resistor and power section
max. device power
dissipation (with inverter,
chopper and rectifier losses;
without internal continuous
braking resistor power)
P
Diss,Drive
W 120 120 270 300
min. insulation resistance at
DC500V
R
is
MOhm 1 8 8 8
coupling capacitance power
section against housing
C
Kop
nF 210 210 210 210
sound pressure level
(accuracy class 2)
dB (A)
67 67 71 71
Fig. 6-13: Data power section - cooling, power dissipation, insulation
resistance, sound pressure
