Rexroth IndraDrive C Electrical Data 6-23

DOK-INDRV*-HCS02.1****-PR02-EN-P

Bottom

hcs0028_x3_x5_x6.fh7

1234

XS2

Fig. 6-23: HCS02.1E-W0012 power section connections (bottom)

Description of connections:

Connection Page

X3, Mains connection 6-28

X5, Motor connection 6-30

X6, Motor temperature monitoring, motor holding brake 6-32

XS2, Shield connection (motor cable) 6-42
