REXROTH HCS02.1 Series User Manual

6-26 Electrical Data Rexroth IndraDrive C
DOK-INDRV*-HCS02.1****-PR02-EN-P
Bottom (HCS02.1E-W0054, -W0070)
hcs0054_x3_x5_x6_x9.fh7
X6
X3
X5
X9
1234
XS2
Fig. 6-26: HC02.1E-W0054, -W0070 power section connections (bottom)
Description of connections:
Connection Page
X3, Mains connection 6-28
X5, Motor connection 6-30
X6, Motor temperature monitoring, motor holding brake 6-32
X9, External braking resistor 6-35
XS2, Shield connection (motor cable) 6-42
