Step three: Connecting the power cable to the battery box
If the power cable’s head is not properly aligned with the battery
box’s port, forcing the connection may result in damage to both.
Ensure the power cable has no damage or exposed wiring.
Locate the other (unconnected) end of the power cable beneath the seat.
Locate the pre-installed battery box beneath the seat. (The battery box is black with
a warning label on top and a handle on the front.)
1)
2)
On the back of the battery box is a connection port. Align the power cable’s head
with the battery box’s connection port. Firmly push until they are FULLY connected.
3)
Lock the connection in place by spinning the metal locking ring clockwise until it is
fully tightened.
4)
Pull the power cable’s rubber safety cover over the connection.6)
Push the controller cable’s rubber safety cover until it touches the other safety cover.7)
Step two: Connect the controller cable to the power cable (cont.)
Assembly (Cont.)
13
