APPENDIX B: WATER MAKE-UP FLOAT VALVE.
A mechanical float valve assembly is provided as standard to supply make-up water to basin. The standard
make-up assembly consist of a heavy duty bronze make-up valve connected to a plastic or copper float
using a threaded stem.
The water level in the basin can be adjusted by repositioning the float and stem using locknuts. The float
valve is easily accessible from outside the unit through removable air inlet louver.
If inlet pressure to the mechanical float valve exceeds 50 psi.
WARRANTY VOID
Figure AP-7: Float valve parts
Float valve installed in a Cooling Tower
Example of stems
Copper float
Plastic float Example of valves
1 ½”
1”
½”
