Reznor, Photon, Installation Manual, EN 2024-01, D301310 Iss 5 Page No 29 of 52
MS
Maintenance
Photon 10-20 component layout
LED status
light
Reset switch
and burner
lockout
Combustion fan
LC3 limit
control bracket
and reset
Modulating
gas valve
Controls
bracket
Axial fan
LC1 limit control
mounting bracket
Gas connection
Burner on
indicator
Burner
Venturi
