Reznor, Photon, Installation Manual, EN 2024-01, D301310 Iss 5 Page No 31 of 52
MS
Photon 100 component layout
Combustion fan
LC1 and LC3
limit control
bracket
Modulating
gas valve
Controls
bracket with
LC3 reset
Axial fan x2
Gas connection
LED status
light
Reset switch
and burner
lockout
Burner on
indicator
Burner
Venturi
