Page No 30 of 52 Reznor, Photon, Installation Manual, EN 2024-01, D301310 Iss 5
MS
Photon 25-70 component layout
Combustion fan
LC1 and LC3
limit control
bracket
Modulating
gas valve
Controls
bracket with
LC3 reset
Axial fan
Gas connection
Burner
Venturi
LED status
light
Reset switch
and burner
lockout
Burner on
indicator
