Reznor UEZ - Controls

CONTROLS
NOTE: Refer to the TROUBLESHOOTING section for probable causes and reset instructions for
the following controls.
Locations for the following controls are shown in Figure 27.
36
UEZ-IOM (07-23) 1034347-I
VENTER
MOTOR
COMBINATION
GAS VALVE
HIGH TEMPERATURE LIMIT CONTROL
VENT TEMPERATURE
LIMIT SWITCH
PRESSURE SWITCH
FLAME
SENSOR
FAN
MOTOR
IGNITOR
INTERLOCK
DOOR
SWITCH
DISCONNECT
SWITCH
TRANSFORMER
DSI CONTROL MODULE
UNIT SIZES 130–310
UNIT SIZES 055–110
PRESSURE SWITCH
TRANSFORMER
DSI CONTROL MODULE
FLAME SENSOR
FLAME ROLLOUT SWITCH
IGNITOR
DISCONNECT SWITCH
FAN MOTOR
HIGH TEMPERATURE
LIMIT CONTROL
COMBINATION GAS VALVE
VENT TEMPERATURE
LIMIT SWITCH
VENTER MOTOR
INTERLOCK DOOR SWITCH
Figure 27. Component Locations
