Reznor VPS - Technical Details

12
1.8 Technical Details - Table 5
No of Injectors
1
Gas Connection
½” N.P.T
Electrical Supply
120 volt 1 phase 60Hz
Vent size (in)
4” or 6” (101mm or 152mm)
Unitary Fan Motor Details
120 volt 1 phase 60Hz
Current Rating
1.2A MAX
Ignition
Electronic Program Start up with Spark Ignition
MODEL
Natural Gas LP Gas
Min. Heater
Length
Max. Heater
Length
Min. Heater
Length
Max. Heater
Length
BTU/Hr BTU/Hr
S ft (m) S ft (m) U ft (m) U ft (m)
60
60,000 60,000 20 (6.1) 40 (12.1) 20 (6.1) 40 (12.1)
80
80,000 80,000 20 (6.1) 40 (12.1) 20 (6.1) 40 (12.1)
100
100,000 100,000 30 (9.1) 50 (15.2) 40 (12.1) 40 (12.1)
125
123,500 125,000 40 (12.1) 60 (18.3) 40 (12.1) 60 (18.3)
150
150,000 150,000 40 (12.1) 70 (21.3) 40 (12.1) 60 (18.3)
170
169,000 169,000 50 (15.2) 80 (24.4) 60 (18.3) 80 (24.4)
200 200,000
N/A
50 (15.2) 80 (24.4) 60 (18.3) 80 (24.4)
N/A
Appliances can be installed up to 10,000 ft in the USA. Altitude conversion kits are available on request.
USA Natural Gas 0- 2000 ft (0-610m)
Size
60 80 100 125 150 170 200
“WC
4.2 3.5 3.5 4.1 4.2 3.4 3.5
USA LP Gas 0- 2000 ft (0-610m)
Size
60 80 100 125 150 170 200
“WC
6.0 5.2 8.2 6.6 7.0 5.7 N/A
USA Natural Gas 2001- 4000 ft (611-1220m)
Size
60 80 100 125 150 170 200
“WC
4.0 3.3 3.3 3.9 4.0 3.2 3.3
USA LP Gas 2001- 4000 ft (611-1220m)
Size
60 80 100 125 150 170 200
“WC
5.8 5.0 8.0 6.4 6.8 N/A
CANADA Natural Gas 0- 2000 ft (0-610m)
Size
60 80 100 125 150 170 200
“WC
4.2 3.5 3.5 4.1 4.2 3.4 3.5
CANADA LP Gas 0- 2000 ft (0-610m)
Size
60 80 100 125 150 170 200
“WC
6.0 5.2 8.2 6.6 7.0 5.7 N/A
CANADA Natural Gas 2001- 4500 ft (611-1370m)
Size
60 80 100 125 150 170 200
“WC
4.0 3.3 3.3 3.9 4.0 3.2 3.3
CANADA LP Gas 2001- 4500 ft (611-1370m)
Size
60 80 100 125 150 170 200
“WC
5.8 5.0 8.0 6.4 6.8 N/A
