Reznor VPS - Page 25

25
Figure 15. Heater Assembly: Model Linear 170-S80 and 200-S80
DETAIL
SLIDING REFLECTOR BRACKET
DETAIL
FIXED REFLECTOR BRACKET
REFLECTOR
TUBE
STRAP
RADIANT
TUBE
2 x SCREWS TIGHTEN TO
FIX REFLECTOR
2 x SCREWS MIN 1/8" GAP TO
ALLOW REFLECTOR TO SLIDE
SUPPLIED
NUT &
BOLT
SF
G GH
S
BURNER
END
CAPS
(OPTIONAL)
6"
4"
81'6½" NOMINAL OVERALL ASSEMBLED LENGTH
END
CAPS
(OPTIONAL)
DISTANCE BETWEEN
SUSPENSION POINTS
NO TO EXCEED 12'
10' 3" REFL'S
TYPICAL OF 8
G
F
3" OVERLAP
GGG
S
HT COUPLER
6" OVERLAP
G
F
HT COUPLER
6" OVERLAP
G
S
3" OVERLAP
F
3" OVERLAP
F
3" OVERLAP
S
3" OVERLAP
C
L
2" MINIMUM
REFLECTOR OVERLAP
FIRST SUSPENSION POINT TUBE STRAP
DETAIL
TUBE & REFLECTOR SUSPENSION BRACKET
DETAIL
TUBE
STRAP
RADIANT
TUBE
SUPPLIED
NUT & BOLT
SUSPENSION
BRACKET
REFLECTOR
H G
"A"
VIEW ON "A"
STANDARD 4" COUPLER
COUPLER COUPLER COUPLER COUPLER COUPLER
