Operating and installation instructions RF-KIT Power Amplifier RF2K-S
Table of contents
1. Explanation of symbols, Environment protection 3
1.1 Explanation of symbols 3
1.2 Environment protection 3
1.3 Transport package 3
2. Safety informations 4
3. Control elements and connections 5
3.1 Panel description 5
3.2 Control elements and connections 6
4. Preparing for operation 7
4.1 Unpacking 7
4.2 Scope of delivery 7
4.3 Selecting a location 7
4.4 Grounding 7
4.5 Connecting exciter 7
4.6 Connecting PTT-cable 7
4.7 Preparing LAN connection 7
4.8 Connecting antenna(s) 7
4.9 AC power cable connection 7
Dear customer,
Congratulations on your purchase of a RF-KIT linear amplier!
RF-KIT devices oer innovative and reliable technology, functionality and
appealing design.
If, in spite of our careful quality control, you have any reason to complain
or have a question about the device, please contact the dealer you trust or
even directly to RF-KIT.
vy 73 es gd dx de
RF-KIT Reinhard Foertsch
Heuleithe 14 · 91322 Graefenberg
Germany
Tel.: 0049 9192 99 66 89
www.rf-kit.de
eMail: info@rf-kit.de
DX Engineering
1200 Southeast Ave.
Tallmadge, OH 44278 USA
© 2019 by RF-KIT Reinhard Foertsch
Errors and omissions excepted. The removal of the copyright notice and
the use of content, even in part, violates applicable law and is expressly
prohibited.
5. Using the device locally 8
5.1 Turning device on/o 9
5.2 User menu 9
5.2.1 Update 9
5.2.2 Settings 10
5.2.3 Antennas 12
5.2.4 LAN/WiFi/VNC 13
5.2.5 Status 16
5.2.6 Rigcontrol 17
6. Antenna tuner 20
6.1 Operation 20
6.2 Input Power for tuning 21
6.3 Manual tuning 21
6.4 Automatic tuning 22
6.5 Indication area Segment-Size 23
6.6 Bypass the antenna tuner 23
7. Technical data and characteristics 25
7.1 Technical data 25
7.2 Characteristics 25
