HOW TO MEASURE FOCAL POINT
HD SERIES MOUNTS
Most "low signal" can be attributed to
improper focal point. The following will
assist you in determining if you have
problems with your reflector or LNB arm.
If the focal point is found
to be non
-compliant then a
djust the
focal point by apply
ing pressure to the outer lip of
the dish and
bending slightly upw
ard. This will sho
rten the focal point.
See
arrows below
.
11
13
