Wiring Diagram
For the Control Cable 12 Pin Connector
Wiring Color Code
Pin Color Color How Used
MotoSAT RF Mogul
Cable GPS
1. Black Motor, Azimuth
2. Brown Motor, Azimuth/Skew
3. Red Motor, Elevation/Skew
4. Orange Motor, Elevation
5. Not Used Not Used
6. Not Used Not Used
7. Yellow Sensor Count, Azimuth
8. 8. Blue Sensor Count, Elevation
9. 9. Purple Sensor Count, Skew
10.
11. 10.* Green Black Ground
11.* Red /Blue Light Adapter Power and Blue light Connection
12. White GPS TXD (Data)
Note: Pins 10 and 11 have a dual function
Pin 10 - Green (MotoSAT Cable) Black (GPS Cable) is used as Ground.
Pin 11 - Red (for GPS) Blue Light Adapter (for Blue LED) is used as
for DC voltage the GPS and Blue Light.
Note: The WHITE wire from the existing MotoSAT control cable spliced to the
"Blue Light Adapter" will maintain the blue light on your reflector at all times.
To turn OFF the Blue Light, remove the power to the Eagle controller.
CAUTION---do not attach the white wire directly to pin #11 without the blue
light adapter. Damage to the blue light on your dish will occur.
1. The GPS cable has a YELLOW, GREEN and
SHIELD wire in the bundle. They will not be used
and can be removed.
2. Carefully cut and remove all stranded shield
3. Inspect for small wire strand shorting across pins.
