9
Connection of Blue Light
Adaptor using a snap t
ype
connector.
For splicing, cu
t
wire
blunt before
inserting into t
he
Scotch L
ock
connector.
Note: If you do not wire this
connector properly damage to
your mount could be a result.
Double
check all connections
before applying power.
Connecting the Blue
Light Adapt
or
White wire from
MotoSAT cable
GPS Cable
Blue Light adaptor
8
10
