RF-43UP
www.szrfstar.com V1.3 - Jan., 2020
Shenzhen RF-star Technology Co., Ltd. Page 26 of 34
0
1
0
750
The transmitting module works in the wake-up mode and will
continuously transmit the call code for the corresponding time.
The receiving module works in low-power mode. This time refers to the
listening interval time (wireless wake-up) of the receiver and can only
receive data from the transmitting module working in wake-up mode.
0
1
1
1000
1
0
0
1250
1
0
1
1500
1
1
0
1750
1
1
1
2000
bit2 is reserved unused.
bit1 and bit0 indicate the transmit power.
bit1
bit0
Transmit Power
(Approximate Value)
Description
0
0
30 dBm (by default)
The external power supply must provide more than 250 mA current
output capability. And ensure that the power supply ripple is less than
100 mV. It is not recommended to use smaller power transmission,
because its power utilization efficiency is not high.
0
1
27 dBm
1
0
24 dBm
1
1
20 dBm
7.2.3 Examples
Examples: 1. Normal mode, 2. Push-pull output, 3. Wireless wake-up time of 500 ms, 4. Transmit power of 30 dBm. It
needs to be expressed as follows: (bit 2 is reserved unused and default as 0)
[1 001 0 00], converted to hexadecimal = [48]
The above can be expressed as: [AT_SET=03,E8,25,17,48]. What it means: All set parameters are saved after powered
off. The parameters are modified to: module address of 1000, serial parity bit of 8N1, baud rate of 19200, air rate of
19.2k, channel of 23 (frequency 433), normal mode, push-pull output, wake-up time of 500 ms and transmit power of 30
dBm.
Here are some common commands:
1. The second group of data: address
Address Number
In Hex
Address 1
00 01
Address 2
00 02
Address 3
00 03
Address 30
00 1E
Address 31
00 1F
