RF-43UP
www.szrfstar.com V1.3 - Jan., 2020
Shenzhen RF-star Technology Co., Ltd. Page 27 of 34
Address 32
00 20
Address 60
00 3C
Address 61
00 3D
Address 62
00 3E
Address 101
00 65
Address 102
00 66
Address 103
00 67
2. The third group of data: serial parity bit, baud rate, air rate
Serial Parity Bite
Baud Rate (bps)
Air Rate (bps)
In Binary
In Hex
8N1
9600
0.3k
00 011 000
18
8N1
9600
2.4k
00 011 010
1A
8N1
9600
19.2k
00 011 101
1D
8N1
19200
0.3k
00 100 000
20
8N1
19200
2.4k
00 100 010
22
8N1
19200
19.2k
00 100 101
25
8N1
115200
0.3k
00 111 000
38
8N1
115200
2.4k
00 111 010
3A
8N1
115200
19.2k
00 111 101
3D
8O1
9600
0.3k
01 011 000
58
8O1
9600
2.4k
01 011 010
5A
8O1
9600
19.2k
01 011 101
5D
8O1
115200
0.3k
01 111 000
78
8O1
115200
2.4k
01 111 010
7A
8O1
115200
19.2k
01 111 101
7D
3. The fourth group of data: channel
Interval: 1M. 116 channels in total.
Channel Number
Frequency (MHz)
In Hex
1
410
01
10
420
0A
20
440
14
